SERVO-U is the next step forward in making protective ventilation more accessible, understandable and easy to implement. It is designed to enhance user confidence in tailoring treatments to the individual patient condition. Which means more patients in all phases of ventilation – controlled, supported, Non-invasive and during spontaneous breathing trials – can benefit from advanced lung protective strategies.



SERVO-U offers:
• Tools to support protective ventilation strategies, such as ARDSNet and NAVA®
• Context-based guidance, therapeutic workflows and intuitive user interaction for all functions
• Upgradeable platform that grows with your needs

SERVO-n has been created to help you provide vulnerable neonates with the support they need while protecting the lungs, brain and other developing organs.



• SERVO-n is sensitive and fast in conventional modes and accurately delivers the pressure and volumes you set, down to 2 ml, while compensating for variable leakage.

• SERVO-n enables you to monitor the electrical activity of the diaphragm (Edi). This signal reflects the neonate’s neural respiratory drive, breath by breath. With it you can ensure the level of assist that’s best at any given time, in any mode of ventilation.

• SERVO-n includes Neurally Adjusted Ventilatory Assist (NAVA), a ventilation mode with the capability to truly match assist to the irregular breathing pattern of neonates. There are many benefits with using NAVA, such as reduced work of breathing, lower peak pressures and FiO2, and improved comfort. All of these help you keep neonates breathing spontaneously, while potentially reducing the need for sedation and time on ventilation.

• SERVO-n makes setting up, monitoring and operating surprisingly simple and intuitive. You’re never more than a touch away from onscreen help and suggestions based on current use.

The flexible and adaptable ventilator for all patient categories meets today's - and tomorrow's - need for different treatment modalities and clinical situations.
SERVO-i® Universal is available in two editions - Universal Basic and Universal Extended. While the Basic edition offers basic functions for treating all patient categories, Extended edition also offers a wider range of treatment modalities as standard.

Some of the key features and benefits of SERVO-i Universal are:

• Enables treatment of all patient categories
• Transportation with no loss of treatment quality within and between hospitals
• Allows for investigation of different treatment options like OPEN LUNG TOOL® and AUTOMODE®
• SERVO-i Universal can easily be upgraded with additional functionality. MAQUET can offer you to try out new functions or modes during a number of weeks.


• Dimensions: Patient Unit W 300 x D 205 x H415 mm
• User Interface: W 355 x D53 x H 295 mm
• Weight: approx 20 kg (Patient Unit 15 kg, User Interface 5 kg)

If you only have adult patients to treat in your ICU, the SERVO-i Adult configuration is your given choice from a cost and treatment perspective. The standard configuration comprises ventilation modes and functions for stabilized patients. Options like Pressure Regulated Volume Control (PRVC) and Volume Support (VS) can easily be added on.

Find out more about some of the key features and benefits of SERVO-i Adult:

• Supports invasive as well as non-invasive ventilation with leakage compensation
• Transportation with no loss of treatment quality within and between hospitals
• Allows for investigation of different treatment options like OPEN LUNG TOOL and AUTOMODE
• SERVO-i Adult can easily be upgraded with additional functionality and/or a wider patient range.
• Backwards compatibility ensures that future functionality can be added.

MAQUET can offer you to try out new functions or modes during a number of weeks.

• Dimensions: Patient Unit W 300 x D 205 x H415 mm
• User Interface: W 355 x D53 x H 295 mm
• Weight: approx 20 kg (Patient Unit 15 kg, User Interface 5 kg)
• Can be upgraded to Servo-I Universal to meet all patients' categories, from neonates to adults

A wealth of features and functionalities for treating neonatal and pediatric patients.
SERVO-i® Infant offers a wealth of features and functionalities for treating neonatal and pediatric patients. Its unparalleled sensitivity helps clinicians to deliver the best care for the smallest patients.
Some of the key features and benefits of SERVO-i Infant are:



• The sensitive Servo trigger gives a fast response time, which ensures comfort and prevents the patient fighting the ventilator.
• The unique Nasal CPAP ventilation that will ensure that the set CPAP pressure is constantly maintained and thus stabilizes the chest wall, improves oxygenation and recruits collapsed alveoli.
• The Possibility to choose between the ultra fast and precise internal Servo measurement system and Y-sensor measuring, both ensuring a high degree of accuracy in pressure and flow.
• SERVO-i Infant can easily be upgraded with additional functionality and/or a wider patient range.
• Backwards compatibility ensures that future functionality can be added.
• MAQUET can offer you to try out new functions or modes during a number of weeks.
• Can be upgraded to Servo-I Universal to meet all patients' categories, from neonates to adults

Based on proven SERVO technology, ensuring safe, reliable and high quality ventilation.
The SERVO-s® ventilator is based on proven SERVO technology, ensuring safe, reliable and high quality ventilation. By combining state-of-the-art sensitivity and reliability with simplicity, SERVO-s delivers top performance for both adult and pediatric patients in a variety of hospital ventilatory care settings.
Some of the key features of the SERVO-s are:



• Invasive and non-invasive ventilation with leakage compensation
• An intuitive user interface with touch screen, main rotary dial and direct access knobs
• Ease of training, operation, maintenance and cleaning
• Design for shelf mounting and intrahospital transport with mobile Cart
• The sensitive flow trigger and ultra-fast inspiratory flow controller in SERVO-s provides excellent patient interaction and reduced work of breathing.


• Dimensions of ventilator: W 380 x D 300 x H 210 mm
• Weight: approx. 18 kg
• Dimensions of user interface: W 355 x D 53 x H 295 mm
• Screen size and type: 31 cm (12.5'') diagonal TFT-LCD module

EIRUS is a unique continuous monitoring platform for both glucose and lactate that has been adapted specifically for the needs of critical care. EIRUS offers truly continuous, second-by-second monitoring that eliminates the risk for trend gaps. Its multipurpose central venous catheter (CVC) provides normal venous access and microdialysis monitoring, reducing the need for additional lines. Continuous glucose monitoring (CGM) will soon be a standard for critical care everywhere. How smart, safe and convenient that standard will be is up to you.

Brings advanced ICU ventilator performance and anesthesia delivery together in one patient-friendly unit.
MAQUET FLOW-i® brings advanced ICU ventilator performance and anesthesia delivery together in one patient-friendly unit.

Representing the latest standard in anesthesia, FLOW-i enables clinicians to continuously adapt and improve anesthesia care to match the situation at hand while maintaining stable respiratory conditions.

FLOW-i can be used across the widest range of patient groups, including those with acute respiratory demands and pediatric patients.

Modular and ergonomic, FLOW-i is a flexible, adaptable and upgradeable system. Ease of use and training contribute to more efficient use of hospital resources.

Please note, the product may be pending regulatory approvals to be marketed in your country. Contact your MAQUET representative for more information.

FLOW-i comes in three models depending on your needs.
All models feature a rotatable arm for flexible screen positioning, tiltable screens to allow for maximized screen visibility and vertical and horizontal rails for auxiliary equipment.
FLOW-i C20 offers the added storage space of 2-3 optional drawers.
One lockable drawer is always included.
