BM-400K Ultra & BM-400K Max
The BM-400K Ultra and BM-400K Max are advanced swept-source OCT platforms designed for high-speed, high-resolution imaging and comprehensive ophthalmic analysis. Operating at a 1060 nm wavelength and a scan speed of up to 400,000 A-scans/sec, both systems provide detailed anterior and posterior segment imaging with axial optical resolution of ≤6 μm and a best digital resolution of 1.9 μm.
The systems offer extended scanning ranges of up to 30 mm posteriorly and 24 mm anteriorly on the BM-400K Ultra, while the BM-400K Max provides up to 26 mm posteriorly and 24 mm anteriorly. Both feature 12 mm/9 mm scan depths, respectively, with a refractive adjustment range of -35D to +45D.
Integrated Scanning Laser Ophthalmoscopy (SLO) uses an 850 nm wavelength, with a field of view of up to 107.25° on the Ultra and 90° on the Max, a minimum pupil diameter of 2.0 mm, and 128 Hz eye tracking.
Advanced OCT Angiography (OCTA) enables large-area single scans, high-resolution imaging up to 1536 × 1280, and montage scanning of approximately 44 × 42 mm on the Ultra and 42 × 40 mm on the Max. Comprehensive software functions include anterior segment quantification, panoramic analysis, retinal and choroidal thickness/volume measurements, glaucoma analysis, blood-flow quantification, posterior curvature, 3D structure, and 3D vessel visualization.
Together, the BM-400K Ultra and BM-400K Max deliver fast, wide-field, high-resolution OCT, SLO, and OCTA imaging for comprehensive clinical assessment and advanced ophthalmic diagnostics.
YG-250K Swept-Source OCT
The YG-250K is an advanced swept-source OCT system designed for high-speed, high-resolution ophthalmic imaging. Featuring a 1060 nm wavelength and scanning speed of up to 250,000 A-scans per second, it provides detailed anterior and posterior segment imaging with an axial optical resolution of ≤6 μm and a best digital resolution of 1.9 μm.
The system offers a maximum scan length of 30 mm posteriorly and 24 mm anteriorly, with a 12 mm scan depth for both segments and a refractive adjustment range of -35D to +45D. Its integrated Scanning Laser Ophthalmoscopy (SLO) operates at 850 nm, providing a 2.0 mm minimum pupil diameter and 128 Hz eye tracking speed.
The YG-250K also includes comprehensive software functions for anterior segment quantification, panoramic analysis, retinal and choroidal thickness/volume measurements, glaucoma analysis, blood-flow quantification, posterior curvature, and 3D structure and vessel visualization.
Combining high-speed scanning, wide imaging range, and advanced analysis capabilities, the YG-250K delivers a powerful solution for comprehensive ophthalmic diagnostics.
YG-100K Ultra & YG-100K Max
The YG-100K Ultra and YG-100K Max are advanced swept-source OCT systems designed to provide high-speed, high-resolution imaging for comprehensive ophthalmic diagnostics. Operating at a 1060 nm wavelength with a scanning speed of 100,000 A-scans/sec, both models deliver detailed anterior and posterior segment imaging, with axial optical resolution of ≤6 μm, best digital resolution of 1.9 μm, and transverse optical resolution of 10 μm.
The YG-100K Ultra offers a maximum scan length of 26 mm posteriorly and 24 mm anteriorly, while the YG-100K Max provides up to 17 mm posteriorly and 24 mm anteriorly. Scan depth reaches 14 mm posteriorly and 15 mm anteriorly on the Ultra, and 12 mm posteriorly on the Max. Refractive adjustment ranges from -35D to +45D on the Ultra and -20D to +15D on the Max.
Integrated Scanning Laser Ophthalmoscopy (SLO) provides a 90° field of view on the Ultra and 60° on the Max, with an 850 nm wavelength, 2.0 mm minimum pupil diameter, and eye tracking speeds of up to 128 Hz and 60 Hz, respectively.
The integrated OCT Angiography (OCTA) offers anterior scans up to 24 × 24 mm, posterior scans up to 18 × 18 mm on the Ultra and 16 × 16 mm on the Max, with imaging resolution up to 1024 × 1024.
Comprehensive software functions include anterior segment quantification, panoramic analysis, retinal and choroidal thickness/volume measurements, glaucoma analysis, blood-flow quantification, posterior curvature, and 3D structure and vessel visualization.
The YG-100K series combines reliable imaging performance, advanced OCTA capabilities, and powerful analysis tools for efficient and comprehensive eye examination.
